Table 7.1 Continued – L120-190, -420 and -800 typical parts list
Piece No. Quantity Description Piece No. Quantity Description
55-3 7 Hex Head Cap Screw 56-23 1 Pipe Plug
55-4 various Lockwasher 56-25 2 Dowel Pin (L120-420, 800)
55-5 2 Socket Head Cap Screw 57 1 O-Ring Spacer (L120-190)
55-6 various Hex Head Cap Screw (L120-190, 420) 58 1 Tripper Spring
55-7 various Lockwasher 60 1 Terminal Bracket
55-8 2 Drive Screw 61 2 Terminal Strip
55-9 4 Hex Head Cap Screw 61-1 2 Kulka Insulator Strip
55-10 4 Lockwasher 63 2 Fil HD Mach Screw
55-11 2 Lockwasher (L120-190) 64 2 Lockwasher
56-2 various Pipe Plug 65 8 RD HD Mach Screw
56-3 1 Grease Fitting 66 8 Lockwasher
56-5 1 Clevis Pin 67 1 Upper Thrust Bearing Cone
56-6 1 Key 68 2 Fork Spacer (L120-420, 800)
56-7 1 Key 69 1 Handwheel Bearing Cap (L120-420, 800)
56-8 1 Key 70 1 Hinge
56-9 1 Socket Head Set Screw 70-1 various Hex Head Cap Screw
56-10 1 Key 70-2 various Lockwasher
56-11 1 Flat Washer (L120-190) 71 1 Hinge Standard Compartment
56-11 1 Socket Head Set Screw (L120-420, 800) 124 1 Motor
56-12 1 Flat Washer 182 1 Handwheel Spinner Kit
56-13 1 Socket Head Set Screw 200-1 1 Limit Switch Compartment Cover (L120-190, 420)
56-14 1 Key 200-2 various Hex Head Cap Screw (L120-190, 420)
56-15 various Socket Head Cap Screw 200-3 various Lockwasher (L120-190, 420)
56-18 various Socket Head Cap Screw 204 1 M.D.P.I. Sight Glass
56-19 1 Socket Head Set Screw 300 1 Torque Switch
56-20 4 Socket Head Set Screw 305 1 Geared Limit Switch
56-21 4 Lockwasher 310 1 Mechanical Dial Position Indicator
