User instructions - Digital Positioner 3200MD LGENIM0059-01 10/08
35
12 Logix 3200MD Mounting Kits
12.1 Valtek Mounting Kits
Table IX: Valtek Linear Mounting Kits
Spud
25 in
2
50 in
2
* 100-200 in
2
Standard Handwheel Standard Handwheel Standard Handwheel
2.00 164432 164433 164434 164433
2.62 164435 164436 **164437** 164436
2.88 164437 164438
3.38 164439 164440
4.75 164439 164440
* A 50 square", 2.00 spud with live loading requires kit number.
** Live-loading is not available on a 100 in
2
, 2.62 spud.
Table X: Valtork Rotary Mounting Kits*
Spud
25 in
2
50 in
2
* 100-200 in
2
Standard Optional Standard Optional Standard Optional
0.44 135429 135432 135430 135431
0.63 135429 135437 135430 135433 135431
0.75 135429 135438 135430 137212 135431
0.88 135429 135439 135430 137213 135431 135434
1.12 135429 135430 137214 135431 137215
1.50 135429 135430 135431 137216
1.75 135429 135430 135431 137217
* Standard: All rotary valves with standard accessories (end of shaft mount).
Optional: All rotary valves with handwheels or volume tanks (linkage design).
