User instructions - Digital Positioner 3200MD LGENIM0059-01 10/08
5
Table VII: Hazardous Area Certifications
Notied Body
Certication
Option
Approval Entity Parameters Temperature Code
Enclosure
Rating
-10
Explosionproof:
Class I, Div 1, Groups B,C,D
Dust Ignition Proof:
Class II, III, Div 1, Groups EFG
(See Warning No. 1, 2)
Not Applicable T6 T
amb
≤ = 60ºC
NEMA
4X
-10
Intrinsically Safe:
Class I, II, III, Div 1, Groups A,B,C,D
Class 1, Zone 0, AEx ia IIC
(See Warning No. 2,3)
Vmax = 30 Volts
Imax = 100mA
Pmax = 800mW
Ci = 30 nF
Li = 0
(refer to control drawing No.
198736)
T4 T
amb
≤ = 85ºC
T5 T
amb
≤ = 55ºC
NEMA
4X
-10
Non-Incendive:
Class I, Div 2, Groups A,B,C,D
(See Warning No. 2)
Install per NEC Article
501-4 when barriers are
not used.
T4 T
amb
≤ = 85ºC
T5 T
amb
≤ = 55ºC
NEMA
4X
-10
Explosionproof:
Class I, Div 1, Groups B,C,D
Class II, Div 1, Groups E,F,G
Class III
(See Warning No. 1, 2)
Not Applicable -25º ≤ Ta ≤ +40ºC
Type
4X
10
Intrinsically Safe:
Class I, II, III, Div 1, Groups A,B,C,D
(See Warning No. 2, 3)
Vmax = 30 Volts
Imax = 100mA
Pmax = 800mW
Ci = 30 nF
Li = 0
(refer to control drawing No.
198736)
T4 T
amb
≤ = 80ºC
Type
4X
10
Non-Incendive:
Class I, II, Div 2, Groups A,B,C,D
(See Warning No. 2)
Not Required T4 T
amb
≤ = 80ºC
Type
4X
ATEX
-07
Explosionproof (Flameproof):
II 2 GD
Ex d IIB + H
2
Ex tD A21 T95ºC
(See Warning No. 1, 2)
Not Required T5 (T = -40ºC to + 80ºC) IP65
-04 or -15
Intrinsically Safe:
II 1 G
Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Volts
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
Co = 36 nF
T4 (T
amb
-40ºC to + 85ºC)
T5 (T
amb
-40ºC to + 55ºC)
IP65
-03 or -04 or -20
Non-Incendive:
II 3 G
Ex nL nA IIC
(See Warning No. 2)
Not Required
T4 T
amb
-40ºC to + 85ºC)
T5 T
amb
-40ºC to + 55ºC)
IP65
IECEx
-16
Explosionproof (Flameproof):
Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required
T5 (T
amb
-20ºC to + 55ºC)
T5 (T
amb
-40ºC to + 80ºC)
IP65
-21
Intrinsically Safe:
Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Vdc
Ii = 100mA
Pi = 0.8W
Ci = 30 nF
Li = 0
T4 (T
amb
-40ºC to + 85ºC) IP65
-06
Explosionproof (Flameproof):
BR-Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required T5 (-40ºC ≤ Ta ≤ + 80ºC) IP65
-06 or -22
Intrinsically Safe:
BR- Ex ia IIC
(See Warning No. 2, 3)
Ui = 30 Vdc
Ii = 100mA
Pi = 800mW
Ci = 30 nF
Li = 0
Co = 36 nF
T5 (-40ºC ≤ Ta ≤ + 55ºC)
T4 (-40ºC ≤ Ta ≤ + 85ºC)
IP65
KOSHA -07
Explosionproof (Flameproof)
Ex d IIB + H
2
(See Warning No. 1, 2)
Not Required T5 (T = -40ºC to + 80ºC) IP65
c WARNINGS:
1. In order to maintain the explosionproof certications do not remove or loosen covers during operation.
2. To avoid the possibility of static discharge clean only with a damp cloth.
3. The positioner must be connected to suitable rated intrinsically safe equipment, and must be installed in accordance with intrinsically safe installation standards.
®
