99
Housing bearing threaded
lineshaft
3240 Bearing carrier
101 Column pipe 1350 Column pipe 101 Pipe, column
103 Bearing threaded lineshaft 3050.# Connector bearing 103
Bearing, line
shaft,enclosing
117
Bearing sleeve
throttle/bushing
4132 Stuffing box bushing 63 Bushing, stuffing box
125 Plug pipe grease plug 6578.# Threaded plug
131 Guard coupling 7450 Coupling guard
171 Bushing auxiliary throttle 4140 Auxiliary seal
191 Coupling column threaded 6850 Pipe coupling 191 Coupling, column pipe
301 Nut enclosing tube 4110 Stuffing box housing
301 Nut packing injection/lube 4110 Stuffing box housing
302 Plate tube tension 1220 Cover 185 Plate, tube, tension
304 Head discharge 1370 Discharge head 187 Head, surface discharge
304 Plate surface 1370 Discharge head 105 Elbow, discharge
305 Flange top column 189 Flange, top column
306
Coupling column threaded
(duplicate to 191)
6850 Pipe coupling 191 Coupling, column pipe
307 Retainer bearing 3250 Bearing support 193
Retainer, bearing, open
line shaft
308 Tube enclosing top 1917.# Shaft enclosing tube
309 Case discharge 1140 Discharge casing 197 Case, discharge
309 Spool discharge 1140 Discharge casing
310 Bowl 1170.1 Pump bowl 199 Bowl, intermediate
311 Collet drive 2484
Clamping ring impeller
bushing
84 Collet, impeller lock
311 Collet threaded
312 Ring thrust split coupling 7410 Coupling ring 86 Ring, thrust, split
312
Ring thrust split coupling
clamp (312b)
2531 Split retaining ring
312 Ring thrust split impeller 2520
Loose (shaft) collar
shoulder ring
82 Ring, thrust, retainer
313 Case suction 1130 Suction casing 203 Case, suction
314 Spacer flanged 88 Spacer, coupling
315 Barrel 1100 Casing 205 Barrel or can, suction
316 Strainer suction 6531 Suction strainer 209 Strainer
319 Ring wear bowl 1500 Casing wear ring 213 Ring, bowl
320
Bearing threaded discharge
case
3050.# Connector bearing 103
Bearing, line
shaft,enclosing
321
Bearing sleeve discharge
case
3300.# Bearing, bushing 39 Bushing, bearing
322 Bearing sleeve bowl 3300.# Bearing, bushing 39 Bushing, bearing
323 Bearing sleeve suction 3300.# Bearing, bushing 39 Bushing, bearing
325
Screw cap hex/head column
to column
6570.# Screw
326
Screw cap hex/head column
to head
6570.# Screw
326
Stud threaded column to
head
6572.# Stud
326 Stud threaded packing gland 6572.# Stud
