326 Stud threaded seal housing 6572.# Stud
327 Nut hex column to column 6581.# Hexagon nut
327 Nut hex column to head 6581.# Hexagon nut
327 Nut hex packing gland 6581.# Hexagon nut
327 Nut hex seal housing 6581.# Hexagon nut
328 Screw set protective collar 6814.# Grub screw
328 Screw set stuffing box sleeve 6814.# Grub screw
330 Liner tube stabilizer
334 Screw lock adjusting nut 6570.# Screw
335 Key gib 6700.# Key
336 Stand driver f/m head
337
Plug pipe hex/socket
f/discharge case
6578.# Threaded plug
340 Housing packing
341
Valve shut/off f/tank oiler
assy.
342
Regulator sight feed f/tank
oiler assy.
343
Elbow vent f/enclosing tube
nut
344
Lubrication line w/fittings
f/tank oiler assy.
345 Grease zerk stuffing box 3853 Grease nipple
346 Slinger 2540 Oil flinger / oil deflector 40 Deflector
347
Oring stuffing box/throttle
bush. Hsg.
4610.# O-ring
348 Housing throttle/bushing 4210 Mechanical seal housing 83 Box, stuffing
349 Housing seal 4212 Seal plate 83 Box, stuffing
350 Stabilizer tube
351
Screw cap hex/head driver
adapter
6570.# Screw
352
Screw cap hex/head driver
stand
6570.# Screw
353 Nut hex driver stand 6581.# Hexagon nut
354
Stud threaded throttle
bushing housing
6572.# Stud
355
Nut hex throttle bushing
housing
6581.# Hexagon nut
356
Screw cap hex/head bowl to
discharge case
6570.# Screw
357
Nut hex bowl to discharge
case
6581.# Hexagon nut
358
Screw cap hex/head bowl to
bowl
6570.# Screw
359 Pin lock threaded/bowl 2923.# Pin
360
Screw cap hex/head column
to discharge case
6570.# Screw
361
Nut hex column to discharge
case
6581.# Hexagon nut
363 Nut hex flanged coupling 6581.# Hexagon nut
364
Screw cap socket/head
flanged coupling
6579.# Socket head cap screw
366 Screw set lineshaft sleeve 6814.# Grub screw
