418 Washer flat coupling guard
419
Plug pipe stuffing box relief
line
6578.# Threaded plug
420 Washer flat column
421 Clip strainer
422 Screw cap hex/head strainer 6570.# Screw
422
Screw mach submersible
strainer
6570.# Screw
424 Plate serial
425 Screw drive 6570.# Screw
426 Jackscrew bowl to bowl 6575.# Jack screw
427
Jackscrew discharge case to
column
6575.# Jack screw
428 Pin impeller wear ring 2923.# Pin
429 Pin bowl wear ring 2923.# Pin
430 Oring bowl 4610.# O-ring
431 Oring column 4610.# O-ring
432
Oring f/oil lube discharge
case
4610.# O-ring
433 Key keyed/coupling 6700.# Key
434 Ring retaining keyed/coupling 2530 Retaining ring
435 Stud thrust keyed/coupling 6572.# Stud
436
Oring reinforcing tube to
suction case
4610.# O-ring
437 Tube reinforcing
438 Oring reinforcing tube 4610.# O-ring
439 Ring reinforcing
440
Oring top injection tube to
housing
4610.# O-ring
441
Coupling column threaded
f/suction
6850 Pipe coupling
442 Housing bearing stand
443 Retainer oil
444 Bearing ball 3010 Anti-friction bearing
445 Spacer bearing
446 Bearing ball top
447 Stem bearing
448
Pin non-reverse f/4b-100 &
100
449 Spring compression f/4b-100
450 Cap bearing stem
451 Plate lube instructions
452
Screw drive lube instruction
plate
6570.# Screw
453 Nipple pipe level indicator
454 Tee pipe level indicator
455 Plug pipe level indicator 6578.# Threaded plug
456 Gauge oil level
457 Cap pipe level indicator
