VERTICAL TURBINE PUMPS (VTPS) CENTRIFUGAL PUMPS ENGLISH 71569224 – 02-15
Page 73 of 76 flowserve.com
458 Guard bearing stand
459 Sleeve seal 2445 Shaft sleeve
460 Seal mechanical 4200 Mechanical seal 65/80
Seal, mech. Stationary/
rotating elements
461 Collar drive
462 Guard cable f/submersible 8361 Cable guard
463 Plug upthrust (submersible)
464 Screw set upthrust plug 6814.# Grub screw
465
Stud threaded submersible
dr. Adapter to suct. Case
6572.# Stud
466
Nut hex submersible dr.
Adapter to suct. Case
6581.# Hexagon nut
467 Coupling motor submersible 7010 Drive coupling 70 Coupling, shaft
468
Key submersible motor
coupling
6700.# Key
469 Jackscrew motor 6575.# Jack screw
470 Washer flat tail water strainer
471 Coupling flanged assembly 7113 Rigid coupling
472 Cone diffusion
473 Jackscrew stuffing box 6575.# Jack screw
474 Clamp coupling guard
475 Valve check f/submersible 6301 Non-return valve
476 Thrust stand driver/stand 3160 Driver pedestal
477
Thrust stand coupling flg
flexible
7112 Flexible coupling
478 Thrust stand cap upper 3260.2 Bearing cover
479
Thrust stand screw cap
hex/hd upper/cap
6570.# Screw
480 Thrust stand grease zerk cap 3853 Grease nipple
481
Thrust stand fitng pipe plug
upper/cap
6578.# Threaded plug
482
Thrust stand oil/sleeve or
thrust/sleeve
2470 Centring sleeve
483 Thrust stand cap lower 3260.1 Bearing cover
484
Thrust stand screw cap
hex/hd lower/cap
6570.# Screw
485
Thrust stand fitng pipe plug
lower/cap
6578.# Threaded plug
487 Thrust stand key driver 6700.# Key
488 Thrust stand key pump shaft 6700.# Key
489
Thrust stand key thrust
sleeve
6700.# Key
490 Ring retaining teflon bearings
491 Bowl w/wr 1170.2 Pump bowl 199 Bowl, intermediate
492 Impeller w/wr 2200 Impeller 2 Impeller / propeller
493
Bell suction w/wr & case
suction w/wr
1310/1130
Suction bell / suction
casing
55 Bell, suction
494
Stud threaded bowl to
bowl/bell
6572.# Stud
495 Nut hex bowl to bowl/bell 6581.# Hexagon nut
496 Thrust stand vent plug 6521 Vent plug
