Defibrillator/Transcutaneous Pacemaker Analyzer
Using Defibrillator Test Elements
61
Table 5. Energy Measurement Test Measurements
Measurement Unit of Measure Description
Energy Joules Amount of energy discharged by the defibrillator
Peak Voltage Volts Peak voltage detected during the discharge
Peak Current Amperes Peak current detected during the discharge
Pulse Width 50% milliseconds The width of the pulse at 50% of its peak
Pulse Width 10% milliseconds The width of the pulse at 10% of its peak
Table 6. Energy Measurement Test Custom Parameters
Parameter Description
Preset Energy The energy (in Joules) used for the test
The field user is prompted to set the defibrillator to this value.
ECG Waveform The ECG waveform that the Analyzer should simulate during the test
