Fluke 123 User Manual

Fluke 123/124
Users Manual
2
Unpacking the Test Tool Kit
The following items are included in your test tool kit. (see
Figure 1.):
Note
When new, the rechargeable battery pack is not
fully charged. See Chapter 2.
# Description Fluke 123 Fluke 123/S Fluke 124 Fluke 124/S
1 Fluke Test Tool Model 123 Model 123 Model 124 Model 124
2 Rechargeable Battery Pack NiMH NiMH NiMH NiMH
3 Power Adapter/Battery Charger • • • •
4 Shielded Test Leads with Black Ground Leads • • • •
5 Test Lead Black (for Grounding) • • • •
6 Alligator Clips (red, gray, black) • • • •
7 Banana-to-BNC Adapters (black) • (1x) • (2x) • (1x) • (2x)
8 Safety Information + CD-ROM with Users Manuals • • • •
9 Shipment Box • •
10 Optically Isolated RS-232/USB Adapter/Cable • •
11 FlukeView® ScopeMeter® Software for Windows® • •
12 Hard Carrying Case • •
13 10:1 Voltage Probe • •

Fluke 123 Specifications

General

Bandwidth	20 MHz
Sample Rate	25 MS/s
Channels	2
Input Impedance	1 MΩ
Display Size	5.7 inches
Temperature Range	0 °C to 50 °C
Dimensions	232 mm x 115 mm x 50 mm
Display	Digital LCD
Memory Depth	512 points per input
Battery Life	7 hours
Weight	1.2 kg
Safety Category	CAT III 600 V
