Specifications
Miscellaneous
4
69
Miscellaneous
Display
Size.................................... 72 x 72 mm (2.83 x 2.83 in)
Resolution ............................................ 240 x 240 pixels
Waveform Display:
Vertical ............................................. 8 div of 20 pixels
Horizontal ...................................... 9.6 div of 25 pixels
Backlight ..................Cold Cathode Fluorescent (CCFL)
Power
External:..............................via Power Adapter PM8907
Input Voltage ......................................... 10 to 21V DC
Power......................................................... 5W typical
Input Connector...........................................5 mm jack
Fluke 123/124 (Internal Battery Pack):
Battery Power.................... Rechargeable Ni-MH 4.8V
Operating Time ...............6 hours with bright backlight
6.30 hours with dimmed backlight
Charging Time....................... 7 hours with test tool off
60 hours with test tool on
12 .. 20 hours with refresh cycle
Allowable ambient temperature:
during charging.................. 0 to 45 °C (32 to 113 °F)
Memory
Number of Screen + Setup Memories (Fluke 123) .....10
Number of Screen + Setup Memories (Fluke 124) .....20
Mechanical
Size .......................232 x 115 x 50 mm (9.1 x 4.5 x 2 in)
Weight .................................................... 1.2 kg (2.5 lbs)
including battery pack
Interface .................................. RS-232, optically isolated
To Printer ..........................supports Epson FX, LQ, and
HP Deskjet
®
, Laserjet
®
, and Postscript
Serial via PM9080 (optically isolated RS-232
adapter/cable, optional).
Parallel via PAC91 (optically isolated print adapter
cable, optional).
To PC ........................ Dump and load settings and data
Serial via OC4USB (optically isolated RS-232/USB
adapter/cable, optional), using SW90W (FlukeView
®
software for Windows
®
).
