Fluke 1503 User Manual

1507/1503
Users Manual
6
Table 3. Buttons and Indicators
Button/
Indicator
Description
A
Press the blue button to select alternate
measurement functions.
E
Press to configure the Tester for a
polarization index or dielectric absorption
ratio test. The test will start when you press
the T button.
C Sets a pass/fail limit for insulation tests.
L
Test lock. When pressed before the T
button, the test remains active until you
press the lock or test button again to
release the lock.
H
Turns the backlight on and off. The
backlight goes off after 2 minutes.
Button/
Indicator
Description
T
Initiates an insulation test when the rotary
switch is an
INSULATION position. Causes the
Tester to source (output) a high voltage
and measure insulation resistance.
Initiates a resistance test when the rotary
switch is in the ohms position.
I
Unsafe voltage warning. Indicates 30 V or
greater (ac or dc depending on the rotary
switch position) is detected on the input.
Also appears when the display shows 0L in
the b switch positions, and when batt
appears on the display. The Z also appears
when insulation test is active.
J
Pass indicator. Indicates when the
insulation resistance measurement is
greater than the selected compare limit.

Fluke 1503 Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	600 V
Drop proof up to	1 m
Operating altitude	0 - 2000 m
Auto discharge time	0.5 s
Operating vibration	2 G
Overload protection	Yes
Non-operating altitude	0 - 12000 m
Maximum capacitive load	1 µF
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 55 °C
Insulation measurement range	0.01 - 2000 MΩ
Insulation test voltage accuracy	20 %
Operating relative humidity (H-H)	0 - 95 %
Insulation measure accuracy (500V)	1.5 %
International Protection (IP) code	IP40
Battery size	AA
Number of batteries supported	4

Weight and Dimensions

Depth	50 mm
Width	100 mm
Height	203 mm
Weight	550 g
