Fluke 1503 User Manual

1507/1503
Users Manual
8
Table 4 Display Indicators (cont.)
Indicator Description
P d Polarization index or dielectric
absorption ratio test is selected
ZERO Ohms lead zero is active.
VAC, VDC, Ω,
kΩ, MΩ, GΩ
Measurement units
88.8.8 Primary display
V
DC
Volts
1888 Secondary display
COMPARE Indicates selected pass/fail compare
value.
t Insulation test indicator. Appears when
insulation test voltage is present.
Table 5. Error Messages
Message Description
batt
Appears on the primary display and
indicates that the battery is too low for
reliable operation. The Tester will not
operate at all until the battery is replaced.
The B also appears when batt is on the
primary display.
> Indicates an out of range value.
CAL Err Invalid calibration data. Calibrate the Tester.

Fluke 1503 Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	600 V
Drop proof up to	1 m
Operating altitude	0 - 2000 m
Auto discharge time	0.5 s
Operating vibration	2 G
Overload protection	Yes
Non-operating altitude	0 - 12000 m
Maximum capacitive load	1 µF
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 55 °C
Insulation measurement range	0.01 - 2000 MΩ
Insulation test voltage accuracy	20 %
Operating relative humidity (H-H)	0 - 95 %
Insulation measure accuracy (500V)	1.5 %
International Protection (IP) code	IP40
Battery size	AA
Number of batteries supported	4

Weight and Dimensions

Depth	50 mm
Width	100 mm
Height	203 mm
Weight	550 g
