Fluke 1503 - Insulation Specifications

Insulation Testers
Specifications
23
Model 1507
Output Voltage Display Range Resolution Test Current
Accuracy
± (% of Rdg + Digits)
0.01 to 20.00 MΩ 0.01 MΩ
50 V
(0 % to + 20 %)
20.0 to 50.0 MΩ 0.1 MΩ
1 mA @ 50 kΩ ± (3 % + 5)
0.01 to 20.00 MΩ 0.01 MΩ
100 V
(0 % to + 20 %)
20.0 to 100.0 MΩ 0.1 MΩ
1 mA @ 100 kΩ ± (3 % + 5)
0.01 to 20.00 MΩ 0.01 MΩ
250 V
(0 % to + 20 %)
20.0 to 200.0 MΩ 0.1 MΩ
1 mA @ 250 kΩ ± (1.5 % + 5)
0.01 to 20.00 MΩ 0.01 MΩ
20.0 to 200.0 MΩ 0.1 MΩ
500 V
(0 % to + 20 %)
200 to 500 MΩ 1 MΩ
1 mA @ 500 kΩ ± (1.5 % + 5)
0.1 to 200.0 MΩ 0.1 MΩ
200 to 2000 MΩ 1 MΩ
± (1.5 % + 5)
1000 V
(0 % to + 20 %)
2.0 to 10.0 GΩ 0.1 GΩ
1 mA @ 1 MΩ
± (10 % + 3)
