Fluke 1503 User Manual

1
1507/1503
Insulation Testers
Introduction
The Fluke model 1507 and model 1503 are
battery-powered insulation testers (hereafter, "the
Tester"). Although this manual describes the operation of
both Models 1507 and 1503, all illustrations and
examples assume use of model 1507.
These Testers meet CAT IV IEC 61010 standards. The
IEC 61010 standard defines four measurement
categories (CAT I to IV) based on the magnitude of
danger from transient impulses. CAT IV Testers are
designed to protect against transients from the primary
supply level (overhead or underground utility service).
The Tester measures or tests the following:
• AC / DC Voltage • Earth-Bond Resistance
• Insulation Resistance
Contacting Fluke
To contact Fluke, call:
1-888-993-5853 in USA
1-800-363-5853 in Canada
+31-402-678-200 in Europe
+81-3-3434-0181 in Japan
+65-738-5655 in Singapore
+1-425-446-5500 from anywhere in the world
Visit Fluke's web site at: www.fluke.com
Register your Tester at: register.fluke.com

Fluke 1503 Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	600 V
Drop proof up to	1 m
Operating altitude	0 - 2000 m
Auto discharge time	0.5 s
Operating vibration	2 G
Overload protection	Yes
Non-operating altitude	0 - 12000 m
Maximum capacitive load	1 µF
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 55 °C
Insulation measurement range	0.01 - 2000 MΩ
Insulation test voltage accuracy	20 %
Operating relative humidity (H-H)	0 - 95 %
Insulation measure accuracy (500V)	1.5 %
International Protection (IP) code	IP40
Battery size	AA
Number of batteries supported	4

Weight and Dimensions

Depth	50 mm
Width	100 mm
Height	203 mm
Weight	550 g
