3 Phase Power Quality Analyzer
Measurement Configuration
27
To stop a logging session:
1. Tap .
A confirmation message shows on the display.
2. To continue, confirm that you want to stop the logging session.
The Analyzer stores the measurements in memory with this file name convention:
Meter.xxx (xxx = three digits).
Each time a session is stored, the digits increment and save a new file.
To proceed in PQ Meter mode:
1. Select Verify Meter.
The Verify Meter screen shows that the voltage and current probes are correctly
connected (correct phasing and correct probe orientation).
2. If an error has been made, select Correct Digitally at the foot of the screen or push Auto
Correct to apply corrections automatically.
3. If the readings on screen are as expected, push START or go back to Setup.
Setup
In Measurement Settings, the basic setup from the Start Up Wizard shows on the display.
Select any item on screen to adjust these settings.
To p o l o g y
To select a topology, go through the list by dragging the scroll bar at the left side of the list or
tap on the cursor buttons at the top and bottom of the list.
The display updates to show the wiring diagram for each topology.
Nominal Voltage and Frequency
The nominal voltage is the expected voltage of the system. If this is set incorrectly, the voltage
continues to be shown but the resulting power quality reports will be incorrect as they require
the nominal voltage to compare with the allowable deviation. Similarly, the nominal voltage and
nominal frequency may be changed using the same method.
