Fluke 1770 Series User Manual

3 Phase Power Quality Analyzer
Power
13
Power
The Analyzer has options for the power source:
 mains
 measurement line
 battery
 USB-C
Mains Power Source
Setup:
1. Attach the mains adapter MA-C8 to both power supply inputs of the Analyzer. See Figure 8.
2. Connect the power cord into the adapter.
3. Plug the power cord into a wall outlet.
4. The Analyzer automatically turns on and is ready to use in <30 seconds.
5. Push
O to turn off/turn on the Analyzer.
Figure 8. Power Supply
