1773/1775/1777
Users Manual
38
The menu on the left side opens submenus for Communication and Tools Settings:
IP Address
WiFi Client
WiFi Access Point
Remote Display
Reset to Factory Defaults
Copy Service Data to USB
Firmware Update
Instrument Name. Identify the Analyzer with a unique name. The name is typed in with the on-
screen keyboard.
Language. Select the preferred language from a list of available languages. Scoll up and down
in the list to see all available languages.
Time Zone. Set the time where the Anaylzer is in use. Touch the screen and chose the
continent and country. Scroll the list up and down to see all the available countries.
Date and Time. Set the format first from the available options. Chose the option for day,
month, year. Chose the clock type as 12 or 24 hour format with the radio button.
The date and time settings have manual or automatic options:
The automatic sources of time are Internet time if the Anaylzer has an active Ethernet
connection or WiFi signal. For more precise time (for IEC 61000-4-30 Class accuracy) an
internal GPS clock is used. The GPS clock requires a GPS antenna that can pick up the GPS
signal from at least two satellites.
For a manual setting, input the date and time with the on-screen keyboard.
Phase colors. These are assigned by the start-up wizard when the Anaylzer is used for the first
time or has been reset. However, you can adjust these colors on the menu when you select a
global region. Use this same screen to label the phase with letters.
