Digital Multimeters
Features
7
Table 3. Rotary Switch Positions
Switch Position
Function
Any Position When the Meter is turned on, the Meter model number briefly appears on the display.
K AC voltage measurement
Press
(yellow) for low-pass filter () (28 II only)
L DC voltage measurement
600 mV dc voltage range
Press (yellow) for temperature () (28 II only)
Press for continuity test.
e Resistance measurement
Press (yellow) for capacitance measurement.
Diode test
AC current measurements from 0 mA to 10.00 A
Press
(yellow) for dc current measurements, from 0 mA to 10.00 A.
AC current measurements from 0 μA to 6000 μA
Press
(yellow) for dc current measurements from 0 μA to 6000 μA.
