Table 5. Display Features (cont.)
Number Feature Indication
Low battery. XW Warning: To
avoid false readings, which
could lead to possible electric
shock or personal injury,
replace the battery as soon as
the battery indicator appears.
A, μA, mA amperes (amps), microamp, milliamp
V, mV volts, millivolts
μF, nF microfarad, nanofarad
nS nanosiemens
%
Percent. Used for duty cycle
measurements.
Ω, MΩ, kΩ ohm, megohm, kilohm
Hz, kHz hertz, kilohertz
Diode test mode.
AC DC Alternating current, direct current
Number Feature Indication
°C, °F
Degrees Celsius, Degrees
Fahrenheit
610000 mV Displays selected range
HiRes
High resolution (Hi Res) mode.
HiRes=19,999 (28 II only)
Auto
Autorange mode. Automatically
selects the range with the best
resolution
Manual
Manual range mode
The number of segments is relative
to the full-scale value of the selected
range. In normal operation 0 (zero) is
on the left. The polarity indicator at
the left of the graph indicates the
polarity of the input. The graph does
not operate with the capacitance, or
frequency counter functions. For
more information, see “Bargraph”.
The bargraph also has a zoom
function, as described under "Zoom
Mode".
