Fluke 28 II Ex User Manual

28 II Ex
Users Manual
36
Table 8. MIN MAX Functions
Button MIN MAX Function

Enter MIN MAX recording mode. The Product is locked in the range shown before you
started MIN MAX mode. (Set the measurement function and range before you enter MIN
MAX.) The Product beeps each time a new minimum or maximum value is recorded.

(while in MIN MAX mode)
Step through maximum (MAX), minimum (MIN), average (AVG) and current values.
E
PEAK MIN MAX
Select 100 ms or 250 μs response time. (The 250 μs response time is shown by 
on the display.) Stored values are erased. The current and AVG (average) values are not
available when 250 μs is selected.
D Stop recording. Stored values are not erased. Push again to continue recording.

(hold for 1 second)
Exit MIN MAX mode. Stored values are erased. The Product stays in the selected range.

Fluke 28 II Ex Specifications

General

Diode test	Yes
Product type	Digital multimeter
Product color	Black, Red
Frequency range	0.0005 - 199.99 kHz
DC current range	0.0000001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Measuring category	CAT IV 600V
Placement supported	Handheld multimeter
Basic accuracy (frequency)	0.005%
Basic accuracy (DC current)	0.2%
Basic accuracy (DC voltage)	0.05%
Temperature measurement range	-200 - 1090 °C
Battery type	AAA
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	3
Operating altitude	0 - 2000 m
Maximum storage altitude	10000 m
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Depth	198.1 mm
Width	100 mm
Height	6.35 mm
Weight	698.5 g
