Fluke 43B User Manual

Fluke 43B
Users Manual
20
Table 1. Harmonics- and Power Settings
HARMONICS settings POWER settings
%r
Displays harmonics as a percentage of
the total harmonic voltages
(total Vrms value).
FUNDAMENTAL
Uses only the fundamental voltage
and fundamental current for power
calculations.
%f
Displays harmonics as a percentage of
the fundamental voltage.
FULL
Uses the voltage and current of the
full frequency spectrum for power
calculations.
DC..21
DC..33
DC..51
Displays the DC component
of the signal and 21, 33 or
51 harmonics.
For signals with harmonics, power
readings with
FULL selected, will
differ from power readings with
FUNDAMENTAL selected.

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
