Fluke 43B User Manual

Maintenance
Batteries
2
29
Extending Battery Operation Time
Charging the batteries when they are not completely empty reduces the battery
operating time for the Fluke 43B. To keep the batteries in optimal condition,
observe the following guidelines:
• Operate the Fluke 43B on batteries until the
symbol appears at the top of
the screen. This indicates that the batteries are very low and that they need to
be recharged.
• To extend battery operation time, you can refresh the batteries.
During a battery refresh, the batteries will be discharged and charged
completely. A complete refresh cycle takes about 16 hours and should be
done about four times a year.
1
Open the main menu.
2
3
Make sure the Fluke 43B is powered with the
power adapter.
4
Press YES to continue.
Do not disconnect the power adapter.
This will interrupt the refresh cycle.
Note
After start of the battery refresh cycle, the screen will be blank. The
backlight is on during the refresh cycle.
 INSTRUMENT SETUP
 START BATTERY REFRESH

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
