Electromagnetic Immunity
The Fluke 43B, including standard accessories, conforms to the EEC directive
2004/108/EC for EMC immunity as defined by EN-61326-1:2006, with the
addition of the following tables.
Disturbance with STL120 and i400s
• Volts / amps / hertz
• Resistance, Capacitance
• Power
• Harmonics
Table 1
No visible disturbance E= 1 V/m E = 3 V/m E = 10 V/m
80 MHz - 1 GHz 5 mV - 500 V/div
1.4 GHz to 2.0 GHz
5 mV - 500 V/div
n.a
2.0 GHz to 2.7 GHz 5 mV - 500 V/div n.a
n.a
Disturbance with VPS40 and i400s in scope mode
• V AC+DC (True RMS)
Table 2
Disturbance less than 1
% of full scale
E= 1 V/m E = 3 V/m E = 10 V/m
80 MHz - 200 MHz 500 mV - 500 V/div 2V - 500 V/div
200 MHz - 1 GHz (-) 5 mV - 500 V/div
1.4 GHz to 2.0 GHz
(-)
n.a
2.0 GHz to 2.7 GHz (-) n.a
n.a
(-): no visible disturbance
Table 3
Disturbance less than
10 % of full scale
E= 1 V/m E = 3 V/m E = 10 V/m
80 MHz - 200 MHz 200 mV/div 1 V/div
Ranges not specified in Tables 2 and 3 may have a disturbance of more than
10 % of full scale.

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
