Fluke 43B User Manual

Fluke 43B
Users Manual
30
Replacing the Ni-MH Battery Pack
It should not usually be necessary to replace the battery pack. If you do want to
replace the battery pack, follow the instructions below.
Warning
To avoid electrical shock, remove test leads and probes before
opening the battery access cover.
1
Disconnect test leads and probes both at the source and at the
Fluke 43B.
2
Locate the battery access cover on the bottom rear. Loosen the screw
with a flat-blade screwdriver.
3
Remove the battery access cover.
4
Take the battery pack out of the compartment.
5
Disconnect the battery plug from the connector.
6
Install a new battery pack.
Note
Ensure that the battery pack is placed in the battery compartment as
shown in Figure 10. Use only the Fluke BP120MH Ni-MH battery pack.
7
Reinstall the battery cover and secure the screw.
Note
This instrument contains Ni-MH batteries. Do not dispose of this battery
pack with other solid waste. Used batteries should be disposed of by a
qualified recycler or hazardous materials handler. Contact your
authorized FLUKE Service Center for recycling information.

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
