Fluke 43B User Manual

Specifications
Current Probe i400s
3
45
Current Probe i400s
Safety Specifications
Category Rating: CAT III 1000 V and CAT IV 600 V per EN/IEC61010-1,
Pollution Degree 2.
: Tested to US and Canadian standards for compliance to UL 61010-1 and
CAN/CSA C22.2 No.61010-2-32-04
: EN 61010-2-32:2002
Electromagnetic Compatibility (EMC)
Acc. to EN 61326-1, FCC for emission and immunity
Electrical Specifications
Reference Conditions: 23 ± 5 °C, 20 to 75 % RH; conductor centered in jaw
opening; no DC component; no adjacent conductor
40 A Range 400 A Range
Measurement Range: 0.5 A to 40 A 5 A to 400 A
Output: 10 mV/A 1 mV/A
Accuracy:
45 Hz to 3 kHz
2 % + 0.015 A 2 % + 0.04 A
Phase Shift:
(45 Hz to 400 Hz)
0.5 A to 1 A
1 A to 5 A
5 A to 10 A
10 A to 20 A
20 A to 40 A
40 A to 400 A
Unspecified
4°
3°
3°
2°
NA
NA
NA
Unspecified
2°
2°
1.5°
Crest Factor: ≤3 ≤3 to 300 A
≤2.5 to 400 A
Typical Bandwidth: 5 Hz to 10 kHz
Working Voltage: 1000 V ac rms, in compliance with EN61010

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
