Fluke 43B
Users Manual
14
Instrument Setup
To change the instrument’s default settings and prepare the Fluke 43B for use,
follow the instructions in this section.
Begin by selecting the INSTRUMENT SETUP screen from the main menu.
1
Open the main menu.
2
Setting the Date
3
4
Adjust the month (MM).
5
Repeat steps 4 and 5 for day (DD) and
year (YY).
6
Choose the date format.
7
(Mar-15-2001)
(15-Mar-2001)
8
Accept the new date settings.
 INSTRUMENT SETUP
 DATE
MMDDYY 
DDMMYY
10
1998
24
10
MMDDYY 
24

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
