Fluke 43B User Manual

Fluke 43B
Users Manual
8
Main Menu
All functions can be easily selected from the
main menu.
1
Open the main menu.
2
(for example)
INRUSH CURRENT
Measures inrush current and
inrush time (motor start-ups).
OHMS / CONTINUITY / CAPACITANCE
Measures resistance, diodes,
continuity and capacitance (DMM).
TEMPERATURE
Measures temperature with optional
temperature probe.
SCOPE
Dual channel oscilloscope: Volts on
input 1 and Amps on input 2.
 VOLTS
/
AMPS
/
HERTZ

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
