Process Calibrators
Specifications
15
717 Specifications
Accuracy is specified for 1 year after calibration at operation temperatures of -10 °C to +
55 °C. To show the firmware version, start with the unit off and push and hold the lower
center button, it will be or , then push .
Pressure
Table 19. 717 Pressure Specifications
Version 1.2 or Lower
Model Range SI Range Metric Max SI Max Metric
717-30 G (0 to 30) PSI 0 to 206.85 kPa 90 PSI 620 kPa
Version 1.3 to 3.9
717-1G (-1 to 1) PSI (-7 to 7) kPa 5 PSI 34.5 kPa
717-30G (-12 to 30) PSI (-83 to 207) kPa 60 PSI 413 kPa
717-100G (-12 to 100) PSI (-83 to 690) kPa 200 PSI 1379 kPa or 1.4 mPa
717-300G (-12 to 300) PSI
(-83 to 2068) kPa or
2.1 mPa
375 PSI 2586 kPa or 2.6 mPa
717-500G (0 to 500) PSI 3447 kPa or 3.4 mPa 1000 PSI 6895 kPa or 6.9 mPa
717-1000G (0-1000) PSI 6895 kPa or 6.9 mPa 2000 PSI 13790 kPa or 13.8 mPa
717-1500G (0-1500) PSI 10342 kPa or 10.3 mPa 3000 PSI 20684 kPa or 20.7 mPa
717-3000G (0-3000) PSI 20684 kpa or 20.7 mPa 6000 PSI 41369 kPa or 41.4 mPa
717-5000G (0-5000) PSI 34474 kPa or 34.5 mPa 10000 PSI 68948 kPa or 69 mPa
Accuracy: Pressure Accuracy is ±0.05 % of positive range 18 °C to 28 °C.
Temperature coefficient: 0.01 % of range per °C for temperature ranges of between 10 °C to 18 °C and
28 °C to 55 °C.
Version 4.0 or Higher
Model Range Max Accuracy
[1]
6 month 1 year
717 1G
-1 to 1 PSI 5 PSI 0.050 % 0.050 %
-7 to 7 kPa 34.5 kPa
717 15G
-12 to 15 PSI 30 PSI 0.025 % 0.035 %
-83 to 103 kPa 207 kPa
717 30G
-12 to 30 PSI 60 PSI 0.025 % 0.035 %
-83 to 207 kPa 413 kPa
717 100G
-12 to 100 PSI 200 PSI 0.025 % 0.035 %
-83 to 690 kPa 1.4 mPa
717 300G
-12 to 300 PSI 375 PSI 0.035 % 0.050 %
-83 to 2.1 mPa 2.6 mPa
717 500G
0 to 500 PSI 1000 PSI 0.025 % 0.035 %
0 to 3.4 mPa 6.9 mPa
