71X Series
Calibration Manual
16
Table 19. 717 Pressure Specifications (cont.)
Model Range Max Accuracy
[1]
6 month 1 year
717 1000G
0 to 1000 PSI 2000 PSI 0.025 % 0.035 %
0 to 6.9 mPa 13.8 mPa
717 1500G
0 to 1500 PSI 3000 PSI 0.025 % 0.035 %
0 to 10.3 mPa 20.7 mPa
717 3000G
0 to 3000 PSI 6000 PSI 0.025 % 0.035 %
0 to 20.7 mPa 41.4 mPa
717 5000G
0 to 5000 PSI 10000 PSI 0.025 % 0.035 %
0 to 34.5 mPa 69 mPa
717 10000G
0 to 10000 PSI 15000 PSI 0.035 % 0.050 %
0 to 69 mPa 103.4 mPa
[1] In an RF field of 1 V/m to 3 V/m between the frequencies of 1.4 GHz to 2.0 GHz, add 120 counts to
specified accuracy.
Table 20. Pressure Display, Pressure Module Input
Range Resolution Accuracy
Refer to the Instruction Sheet for the pressure module
Table 21. DC mA Input
Range Resolution Accuracy,±( % of Reading + Counts)
717 Version 2.9
or lower 24 mA 0.001 mA 0.025 + 1
717 Version 3.0
or higher
24 mA 0.001 mA 0.015 + 2
