Fluke 719 Series User Manual

Pressure Calibrator with Electric Pump
Parts and Accessories
23
Parts and Accessories
Refer to Table 7 and Figure 11.
Table 7. Replacement Parts
Item Description Part/ Mod. No. Qty
AC72
Alligator clip red
Alligator clip black
1670641
1670652
1
1
BT1, BT2 9 V battery, ANSI/NEDA 1604A or IEC 6LR61 614487 2
Holster Holster, Yellow 664182 1
H2, 3, 4 Case screw 832246 3
H5, 6 Battery door fasteners 948609 2
H7, 8 Bracket screw 641131 2
MP1 LCD bezel, 719 30G 3315359 1
MP1 LCD bezel, 719 100G 3322203 1
MP2 LCD, 719 3345775 1
MP3, 4 Pump retainer bracket kit, 719 3345782 2
MP5 Gasket 664208 1
MP6 Pump and vernier (no motor), 719 3345794 1
MP7, 8 Selector knob 3330278 2

Fluke 719 Series Specifications

General

Accuracy	0.025% of full scale
Current Measurement	0 to 24 mA
Display	LCD
Pressure Media	Non-corrosive gases
Pressure Units	psi, bar, kPa
Resolution	1 µA
Loop Power	24V DC
Operating Temperature	-10 °C to 55 °C
Storage Temperature	-20 °C to 60 °C
Weight	0.65 kg
