719 Series
Users Manual
26
Specifications
Specifications are based on a one year calibration cycle and apply for ambient temperature from +18 °C to +28 °C unless
stated otherwise. Counts are the number of increments or decrements of the least significant digit.
Pressure Sensor Input
Model Range Accuracy
Max Non-
destructive
Pressure
30G
-12 to
36.0 psi
60 psi
100G
-12 to
120.0 psi
± 0.025 % of
Range
(6 month
calibration)
± 0.035 % of
Range
(1 year
calibration)
200 psi
Temperature coefficient: 0.01 % of range per °C for
temperature ranges -10 °C to 18 °C and 28 °C to 55 °C
Pressure Module Input
Range Resolution Accuracy
(determined by Pressure Module)
DC mA Measure and Source
Range Resolution
Accuracy
±(% of Reading +
Counts)
24 mA 0.001 mA 0.015 + 2
Maximum load on mA source is 1000 Ω. With HART
resistor on, maximum load is 750 Ω.
Fuseless overload protection
Temperature coefficient: 0.005 % of range per °C for
temperature ranges -10 °C to 18 °C and 28 °C to
55 °C
Loop Supply
24 V dc nominal
Pressure Source
Model Range
30G -11 to 36.0 psi
100G -11 to 120.0 psi
