Temperature Calibrator
Getting Acquainted with the Calibrator
9
Table 3. Input/Output Terminals and Connectors
No Name Description
A, B
MEASURE V, mA
terminals
Input terminals for measuring voltage, current, and supplying loop power.
C
TC input/output Terminal for measuring or simulating thermocouples. This terminal accepts a miniature
polarized thermocouple plug with flat, in-line blades spaced 7.9 mm (0.312 in) center to
center.
D, E
SOURCE/ MEASURE
V, RTD, Ω terminals
Terminals for sourcing or measuring voltage, resistance, and RTDs.
F, G
MEASURE 3W, 4W Terminals for performing 3W and 4W RTD measurements.
