Fluke 8558A Service Manual

8588A/8558A
Service Manual
8
Configuration: Z in 1 MΩ, 7.5 Digits, Internal Guard, Front Input, Aperture = Auto.
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
100 V 0.000 00 V 0.000 04 V 0.000 05 V 0.000 026 V
100 V 100.000 00 V 0.000 57 V 0.000 83 V 0.000 100 V
100 V 200.000 00 V 0.001 10 V 0.001 61 V 0.000 200 V
100 V 0.000 00 V 0.000 04 V 0.000 05 V 0.000 026 V
100 V -100.000 00 V 0.000 57 V 0.000 83 V 0.000 100 V
100 V -200.000 00 V 0.001 10 V 0.001 61 V 0.000 200 V
1000 V 0.000 0 V 0.000 7 V 0.001 7 V 0.000 30 V
1000 V 500.000 0 V 0.003 4 V 0.005 7 V 0.000 80 V
1000 V 1000.000 0 V 0.006 2 V 0.009 7 V 0.001 60 V
1000 V -500.000 0 V 0.003 4 V 0.005 7 V 0.000 80 V
1000 V -1000.000 0 V 0.006 2 V 0.009 7 V 0.001 60 V
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
100 V 0.000 00 V 0.000 66 V 0.000 66 V 0.000 23 V
100 V 100.000 00 V 0.001 86 V 0.001 96V 0.000 10 V
100 V 200.000 00 V 0.003 06 V 0.003 26 V 0.000 20 V
100 V 0.000 00 V 0.000 66 V 0.000 66 V 0.000 03 V
100 V -100.000 00 V -0.001 86 V 0.001 96V 0.000 10 V
100 V -200.000 00 V -0.003 06 V 0.003 26 V 0.000 20 V
1000 V 0.000 0 V 0.032 05 V 0.032 1 V 0.000 30 V
1000 V 500.000 0 V 0.038 05 V 0.038 6 V 0.000 80 V
1000 V 1000.000 0 V 0.044 05 V 0.045 1 V 0.001 60 V
1000 V -500.000 0 V 0.038 05 V 0.038 6 V 0.000 80 V
1000 V -1000.000 0 V 0.044 05 V 0.045 1 V 0.001 60 V

Fluke 8558A Specifications

General

Brand	Fluke
Model	8558A
Category	Multimeter
Language	English
