Fluke 8558A Service Manual

Reference Multimeter / 8½ Digit Multimeter
Calibration Verification
29
DC Current (Rear Input)
Configuration: 7.5 Digits, Internal Guard, Rear Input, Filter Off, Aperture = Auto
AC Voltage (Rear Input)
Configuration: Input: Rear, Ext Guard: Off, Resolution: 6 digits, Measure Setup: DC 1 MΩ, RMS Filter
40 Hz, Frequency Path Bandwidth Limit: OFF, Band: Wideband
Suggested Reference: 5730A
AC Current (Rear Input)
Configuration: 7.5 Digits, Internal Guard, Front Input, DC Coupled, Wideband RMS Filter 40 Hz.
Suggested Reference: 5730A
Resistance – HV Ohms (Rear Input)
Configuration: 7.5 Digits, Aperture = Auto, 4-wire, Internal Guard, Rear Input, Filter Off.
Suggested Reference: 10 GΩ Standard Resistor
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
100 μA 0.000 00 μA 0.000 50 μA 0.000 60 μA 0.000 12 μA
100 μA 100.000 00 μA 0.001 60 μA 0.001 90 μA 0.000 45 μA
100 mA 0.000 00 mA 0.001 30 mA 0.000 60 mA 0.000 26 mA
100 mA 100.000 00 mA 0.005 60 mA 0.006 80 mA 0.000 58 mA
Range Frequency Reference Value
Permissible Error (±) Fluke
Calibration
Uncertainty (±)
8588A 8558A
1 V 1 kHz 1.000 000 V 0.000 089 V 0.000 100 V 0.000 018 V
10 V 1 kHz 1.000 00 V 0.000 89 V 0.001 00 V 0.000 17 V
Range Frequency Reference Value
Permissible Error (±) Fluke
Calibration
Uncertainty (±)
8588A 8558A
100 μA 1 kHz 100.000 0 μA 0.040 0 μA 0.052 9 μA 0.006 6 μA
100 μA 10 kHz 100.000 0 μA 0.072 3 μA 0.091 6 μA 0.008 1 μA
Range Reference value
Permissible Error (±) Fluke
Calibration
Uncertainty (±)
8588A 8558A
10 GΩ 0.000 000 GΩ 0.012 900 GΩ 0.012 900 GΩ 0.000 010 GΩ
10 GΩ
10.000 000 GΩ 0.019 677 GΩ 0.019 677 GΩ 0.001 600 GΩ
