Fluke 8558A Service Manual

Reference Multimeter / 8½ Digit Multimeter
Calibration Verification
11
Digitize DC Voltage
Configuration: Z in DC Auto, Aperture = 200 ns, Trigger count 101010, Low pass filter Off.
Configuration: Z in DC Auto, Aperture = 200 ns, Trigger count 101010, Low pass filter 100 kHz.
Configuration: Z in DC Auto, Aperture = 200 ns, Trigger count 101010, Low pass filter 3 MHz.
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
1 V 0.000 000 0V 0.000 054 0 V 0.000 054 0 V 0.000 006 0 V
1 V 1.000 000 0V 0.000 157 0V 0.000 157 0V 0.000 006 1 V
1 V -1.000 000 0V 0.000 157 0V 0.000 157 0V 0.000 006 1 V
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
1 V 0.000 000 0V 0.000 019 0 V 0.000 019 0 V 0.000 006 0 V
1 V 1.000 000 0V 0.000 082 0V 0.000 082 0V 0.000 006 1 V
1 V -1.000 000 0V 0.000 082 0V 0.000 082 0V 0.000 006 1 V
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
1 V 0.000 000 0V 0.000 019 0 V 0.000 019 0 V 0.000 006 0 V
1 V 1.000 000 0V 0.000 082 0V 0.000 082 0V 0.000 006 1 V
1 V -1.000 000 0V 0.000 082 0V 0.000 082 0V 0.000 006 1 V
