Fluke 8558A Service Manual

8588A/8558A
Service Manual
26
Resistance - Tru Ohms, Low Current
Configuration: 7.5 Digits, Aperture = Auto, 4-wire, Lo Current On, Internal Guard, Front Input, Filter Off.
Note
The 1 Ω and 10 Ω ranges use the same current as True Ohms and do not need to be verified.
Resistance - HV Ohms
Configuration: 7.5 Digits, Aperture = Auto, 4-wire (2-wire at 100 MΩ), Lo Current Off, Internal Guard,
Front Input, Filter Off.
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
100 Ω 0.000 00 Ω 0.000 26 Ω 0.000 26 Ω 0.000 010 Ω
100 Ω 100.000 00 Ω 0.002 12 Ω 0.002 12 Ω 0.000 210 Ω
100 Ω 190.000 00 Ω 0.003 79 Ω 0.003 79 Ω 0.000 270 Ω
1 kΩ 0.000 000 0 kΩ 0.000 02 6 kΩ 0.000 02 6 kΩ 0.000 000 10 kΩ
1 kΩ 1.000 000 0 kΩ 0.000 022 6 kΩ 0.000 022 6 kΩ 0.000 002 50 kΩ
1 kΩ 1.900 000 0 kΩ 0.000 040 6 kΩ 0.000 040 6 kΩ 0.000 002 50 kΩ
10 kΩ 0.000 000 kΩ 0.000 026 kΩ 0.000 026 kΩ 0.000 001 0 kΩ
10 kΩ 10.000 000 kΩ 0.000 276 kΩ 0.000 276 kΩ 0.000 084 0 kΩ
10 kΩ 19.000 000 kΩ 0.000 501 kΩ 0.000 501 k
Ω 0.000 160 0 kΩ
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
10 MΩ 0.000 000 MΩ 0.000 013 MΩ 0.000 013 MΩ 0.000 001 0 MΩ
10 MΩ 10.000 000 MΩ 0.000 203 MΩ 0.000 203 MΩ 0.000 052 0 MΩ
10 MΩ 19.000 000 MΩ 0.000 374 MΩ 0.000 374 MΩ 0.000 097 0 MΩ
100 MΩ 0.000 00 kΩ 0.001 29 MΩ 0.001 29 MΩ 0.000 010 MΩ
100 MΩ 100.000 00 MΩ 0.008 99 MΩ 0.008 99 MΩ 0.001 900 MΩ
1 GΩ 0.000 000 0 GΩ 0.000 13 GΩ 0.000 13 GΩ 0.000 010 GΩ
1 GΩ 1.000 000 0 GΩ 0.000 32 GΩ 0.000 32 GΩ 0.000 044 GΩ
10 GΩ 0.000 000 GΩ 0.012 90 GΩ 0.012 90 GΩ 0.000 001 0 GΩ
10 GΩ 10.000 000 MΩ 0.019 67 GΩ 0.019 67 GΩ 0.001 600 0 G
Ω
