Reference Multimeter / 8½ Digit Multimeter
Maintenance
31
Fuse Replacement
The line and neutral wires are each protected by a fuse. The fuse rating label below the fuse holder
shows the correct replacement fuses. Line and neutral are fused individually. The same fuses are used
for both 100 V to 120 V and 200 V to 240 V operation.
XWWarning
To prevent possible electrical shock, fire, or personal injury:
• Turn the Product off and remove the mains power cord. Stop for 2 minutes to let the
power assemblies discharge before you open the fuse door.
• Replace a blown fuse with exact replacement only for continued protection against
arc flash.
• Use only specified replacement fuses, see Table 3.
To access the fuse, see Figure 2:
1. Disconnect the mains power cord.
2. With a standard screwdriver, release the fuse holder door.
3. Pull out the fuse holder.
4. If necessary, replace one or both fuses.
5. Reinsert the fuse holder.
6. Close the fuse holder door.
Table 3. Replacement Fuses
Line Voltage Range Fuse Description- Mains Fuse Fluke Part Number
W 100 V – 120 V
T1.5AH 250 V 2059740
W 220 V – 240 V
Rear Input Current Protection Fuse
- 1.6AH 250V 1582072
