Fluke 8558A Service Manual

8588A/8558A
Service Manual
6
Remote Adjustment
Refer to Manual Adjustment for the process steps. Remote commands are in the Calibration
subsystem section of the 8588A/8558A Programmers Guide found online at www.Flukecal.com
.
Calibration Verification
The permissible errors shown are the 99 % confidence, 1-year, absolute errors. These error values
include Fluke Calibration calibration uncertainty. Adjust the permissible error values to reflect the actual
measurement uncertainty if they are different from the listed values.
DC Voltage
Configuration: Z in Auto, Internal Guard, Front Input, Aperture = Auto, Resolution 7.5 Digits, Suggested
Reference: 5730A
Step Description Input
401 Ohms 4W Offset 0 Ω 4W
402 10 Ω Gain 10 Ω 4W
403 100 Ω Gain 100 Ω 4W
404 1 kΩ Gain 1 kΩ 4W
405 10 kΩ Gain 10 kΩ 4W
406 100 kΩ Gain 100 kΩ 4W
407 1 MΩ Gain 1 MΩ 4W
408 10 MΩ Gain 10 MΩ 4W
409 100 MΩ Gain 100 MΩ 4W
410 1 GΩ Gain 1 GΩ 4W
411 1 Ω Zero 0 Ω 4W
412 1 Ω Gain 1 Ω 4W
501
[1]
Capacitance Zero N/A
502
[1]
1 nF Gain 1 nF
601 Frequency 10 MHz (Rear BNC)
701 Voltage Zero N/A
702 Resistance Zero 4W 4W Short Circuit
703
Current Zero N/A
704
[1]
Capacitance Zero N/A
[1] Points are unavailable in 8558A.
Table 2. Table Points (cont.)
