Fluke 8558A Service Manual

Reference Multimeter / 8½ Digit Multimeter
Calibration Verification
27
Frequency
Configuration for frequencies ≤1 MHz: Bandwidth Limit Off, Input Path ACV signal, Range 1 V, Gate
1 s.
Configuration for frequencies >1 MHz, Input Path Rear BNC, Gate 1 s, Z in 50 Ω.
Capacitance
Configuration: Resolution 5 digits, LoI Off.
Suggested Reference: Fluke 5522A, 1 nF Standard Capacitor.
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
10 Hz 10.000 000 0 Hz 0.000 010 0 Hz 0.000 010 0 Hz 0.000 001 0 Hz
1 kHz 1.000 000 00 kHz 0.000 001 00 kHz 0.000 001 00 kHz 0.000 000 10 kHz
10 kHz 10.000 000 0 kHz 0.000 010 0 kHz 0.000 010 0 kHz 0.000 001 0 Hz
100 kHz 100.000 000 kHz 0.001 00 kHz 0.001 00 kHz 0.000 010 kHz
1 MHz 1.000 000 00 MHz 0.000 001 00 MHz 0.000 001 00 MHz 0.000 000 10 MHz
10 MHz 10.000 000 0 MHz 0.000 008 6 MHz 0.000 009 2 MHz 0.000 001 0 MHz
100 MHz 100.000 000 MHz 0.000 086 MHz 0.000 092 MHz 0.000 010 MHz
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
1 nF 0. 000 00 nF 0.001 00 nF n/a 0.000 020 nF
1 nF 1. 000 00 nF 0.002 54 nF n/a 0.000 300 nF
1 nF 2.000 00 nF 0.003 88 nF n/a 0.000 600 nF
10 nF 10.000 0 nF 0.010 4 nF n/a 0.001 90 nF
10 nF 20.000 0 nF 0.018 2 nF n/a 0.003 80 nF
100 nF 20.000 nF 0.023 39 nF n/a 0.001 6 nF
100 nF 100.000 nF 0.065 47 nF n/a 0.008 0 nF
100 nF 200.000 nF 0.118 07 nF n/a 0.016 0 nF
1 μF 0.200 00 μF 0.000 23 μF n/a 0.000 014 μF
1 μF 1.000 00 μF 0.000 65 μF n/a 0.000 068 μF
1 μF 2.000 00 μF 0.001 18 μF n/a 0.000 570 μF
10 μF 2.000 0 μF 0.002 3 μF n/a 0.000 20 μF
10 μF 10.000 0 μF 0.006 5 μF n/a 0.000 91 μF
100 μF 100.000 μF0.091 μF n/a 0.007 7 μF
100 μF 200.000 μF0.169 μF n/a 0.015 0 μF
