Fluke 8558A Service Manual

Reference Multimeter / 8½ Digit Multimeter
Calibration Verification
13
Configuration: 7.5 Digits, Internal Guard, Front Input, Filter Off, Aperture = 99 μs
.
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
100 mA 0.000 00 mA 0.001 30 mA 0.001 90 mA 0.000 26 mA
100 mA -100.000 00 mA 0.005 60 mA 0.006 40 mA 0.000 58 mA
100 mA -200.000 00 mA 0.009 90 mA 0.010 90 mA 0.001 20 mA
1 A 0.000 000 0 A 0.000 129 0 A 0.000 190 0 A 0.000 002 6 A
1 A 1.000 000 0 A 0.000 259 0 A 0.000 350 0 A 0.000 025 0 A
1 A 2.000 000 0 A 0.000 389 0 A 0.000 500 0 A 0.000 049 0 A
1 A 0.000 000 0 A 0.000 129 0 A 0.000 190 0 A 0.000 002 6 A
1 A -1.000 000 0 A 0.000 259 0 A 0.000 350 0 A 0.000 025 0 A
1 A -2.000 000 0 A 0.000 389 0 A 0.000 500 0 A 0.000 049 0 A
30 A 0.000 000 A 0.000 520 A n/a 0.000 071 A
30 A 10.000 000 A 0.003 540 A n/a 0.000 420 A
30 A 30.000 000 A 0.024 660 A n/a 0.000 760 A
30 A 0.000 000 A 0.000 520 A n/a 0.000 071 A
30 A -10.000 000 A 0.003 540 A n/a 0.000 420 A
30 A -30.000 000 A 0.024 660 A n/a 0.000 760 A
Range Reference Value
Permissible Error (±)
Fluke Calibration
Uncertainty (±)
8588A 8558A
10 μA 0.000 000 μA 0.001 03 μA 0.001 03 μA 0.000 140 μA
10 μA 10.000 000 μA 0.001 63 μA 0.001 63 μA 0.000 240 μA
10 μA 20.000 000 μA 0.002 23 μA 0.002 23 μA 0.000 480 μA
10 μA 0.000 000 μA 0.001 03 μA 0.001 03 μA 0.000 140 μA
10 μA -10.000 000 μA 0.001 63 μA 0.001 63 μ
A 0.000 240 μA
10 μA -20.000 000 μA 0.002 23 μA 0.002 23 μA 0.000 480 μA
100 μA 0.000 00 μA 0.009 00 μA 0.009 00 μA 0.000 47 μA
100 μA 100.000 00 μA 0.014 70 μA 0.014 70 μA 0.000 79 μA
100 μA 200.000 00 μA 0.002 40 μA 0.002 40 μA 0.001 60 μA
100 μA 0.000 00 μA 0.009 00 μA 0.009 00 μA 0.000 47 μA
100 μA -100.000 00 μA 0.014 70 μA 0.014 70 μA 0.000 79 μA
100 μA -200.000 00 μA 0.002 40 μA 0.002 40 μA 0.001 60 μA
