Fluke 8558A Service Manual

Reference Multimeter / 8½ Digit Multimeter
List of Replaceable Parts
35
Reference
Designator
Description
Fluke Stock
Number
Qty
MP28 BINDING POST-BLACK 2438091 2
MP29 BINDING POST-GREEN 4496766 1
MP30 BINDING POST-BLUE 4496753 1
W1 TRANSFORMER ASSEMBLY 4840852 1
W2 FRONT TERMINALS CABLE ASSY 4841087 1
W3 REAR INPUT CABLE ASSEMBLY 4841093 1
W4 MAINS INPUT CABLE ASSY 4841112 1
W5 CONNECTOR ASSY TRIGGER 4841101 1
W6 CABLE RIBBON 50 WAY 4888687 1
W7 CABLE RIBBON 20 WAY 4888717 2
F1 FUSE MAINS 2059740 2
F2 FUSE REAR INPUT 1582072 1
F3 POWER ENTRY MODULE 4888721 1
H1 BINDING POST 102707 1
H2 BINDING HEAD 102889 1
H3 IEEE MOUNTING JACK SCREWS 836585 1
H4 WASHER M5 SPRING IEEE JACK SCREWS 4196138 2
H5 SCREW LOW PROFILE M4 TORX (HANDLE) 4880050 16
Table 4. List of Replaceable Parts (cont.)
