Fluke 867B Service Manual

867B,863
Service Manual
1-4
Table 1-1. Power Sources
Model 867B Model 863
Battery Eliminator Operation
••
Alkaline Battery Operation (6 AA,
ANSI/NEDA-L40)
••
NiCd Battery Pack Operation (with
internal charging)
•
NiCd Battery Pack Operation (with
external charging)
•
Options, Accessories and Related Equipment 1-4.
Accessories supplied with Fluke 867B and 863 GMMs are listed in Table 1-2.
Table 1-2. Accessories Included with Each GMM
Model 867B Model 863
TL70A Test Leads (2)
••
Battery Eliminator
•
NiCd Battery Pack
•
Operating Instructions 1-5.
Operating instructions for the Fluke 867B and 863 Graphical Multimeters can be found in
the Users Manual. For ordering information, see “How to Obtain Parts” in Chapter 5.
Obtaining Service 1-6.
A GMM under warranty will be promptly repaired or replaced (at Fluke’s option) and
returned at no charge. See the registration card for warranty terms. If the warranty has
expired, the GMM will be repaired and returned for a fixed fee. Contact the nearest
Service Center for information and prices. A list of U.S. and International Service
Centers is available on the World Wide Web at www.fluke.com. Refer to Chapter 3 for a
list of Fluke telephone numbers.

Fluke 867B Specifications

General

True RMS	Yes
Diode Test	Yes
Continuity Check	Yes
Safety Rating	CAT III 1000 V, CAT IV 600 V
Max Voltage AC/DC	1000 V
Max Current AC/DC	10 A
Battery Life	200 hours
