Fluke FTK200 - FS150 Fiber Source Features

Optical Fiber Test Kit
Features
7
1
2
3
FS150
FIBER SOURCE
850
nm
1300
nm
afz03f.eps
A On/off switch. The switch lights up when the source is on and
blinks when the battery is low.
B Slide switch for selecting 850 nm or 1300 nm light output.
C ST connector for 850 nm or 1300 nm light output.
Figure 4. FS150 Fiber Source Features
