FTK200
Users Guide
18
FM150 Fiber Meter Specifications (cont.)
Memory Stores up to 500 measurements for each wavelength. Measurements are stored in non-volatile
memory, which is retained when power is off or the battery is changed.
Memory contents can be uploaded to a PC or sent directly to a serial printer.
Serial port
connector 3.5 mm, 3-conductor phone jack
Certifications
Dimensions
3.2 in x 5.8 in x 1.5 in (8.1 cm x 14.7 cm x 3.8 cm)
Weight
8.6 oz (244 g)
FS150 Fiber Source Specifications
Light source Infrared LED
Wavelength 850 nm ±30 nm; 1300 nm -10 nm/+50 nm
Output power -20 dBm nominal into 62.5 µm multimode fiber
Connector ST
