Optical Fiber Test Kit
FM150 Fiber Meter Specifications
17
Calibration and Service
Have the meter calibrated at an authorized Fluke Service
Center every 12 months.
For service, contact an authorized service center. To
locate the nearest service center, contact Fluke as
described at the beginning of this guide.
FM150 Fiber Meter Specifications
Detector type Germanium
Calibrated wavelengths 850 nm, 1300 nm, 1310 nm, and 1550 nm
Measurement range +6 dBm to -50 dBm
Resolution 0.01 dB
Loss and power
measurement accuracy ±0.25 dB at 25 °C and -10 dBm
Temperature range Operating: 0 °C to +50 °C; Storage: -30 °C to +60 °C
Humidity range Operating: 0 to 95 % RH, non-condensing
Battery type and life 9 V alkaline (NEDA 1604A or IEC 6LR61); 30 hours typical with alkaline battery
Low battery indication BAT appears on the display.
Display 4-digit LCD display
