Pos Description Part Number
U7 IC-OPAMP OPA277 932214746682
U8 IC-OP AMP LM358 x2 SMD SO8 933965740685
U8 IC-OP AMP LM358 x2 SMD SO8 482220960175
U9 IC-ANALOG-PLL 200MHz ADF4001BRU 932220404682
NOTE: The preceding parts lists for the two versions of the main
PCB are both complete for the sake of simplicity. Conse
-
quently there is redundant information.
Parts Unique to Version A
Pos Description Part Number
B3 CRYSTAL 32kHz MC-406 242254301419
R364 RESISTOR 22 kOhm 1% 0.1W 100PPM 0805 403100222030
R367 RESISTOR 22 kOhm 1% 0.1W 100PPM 0805 403100222030
R549 RESISTOR 1 kOhm 1% 0.125W 1206 403100110020
U13 IC-CPU TA7S20-60QC 932220406682
U14 IC-CMOS SN74LVC125AD 932220193682
Parts Unique to Version B
Pos Description Part Number
B7 CRYSTAL 11.2896 MHz HC49/USM SMD 403110056560
C281 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C282 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C283 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C284 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C285 CAPACITOR 470pF 10% 50V X7R 0402 403102040471
C286 CAPACITOR 470pF 10% 50V X7R 0402 403102040471
C287 CAPACITOR 470pF 10% 50V X7R 0402 403102040471
C288 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C304 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C305 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C306 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C309 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C501 CAPACITOR 470pF 10% 50V X7R 0402 403102040471
C506 CAPACITOR 470pF 10% 50V X7R 0402 403102040471
C508 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C513 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C514 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C515 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C516 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C535 CAPACITOR 100nF 10% 16V X7R 0603 403102030104
C568 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C569 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C570 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C571 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
C572 CAPACITOR 10nF 10% 25V X7R 0402 403102040103
R548 RESISTOR 91 kohm 1% 0.1W 100PPM 0805 403100291030
U13 IC-CPU LH79524 403106000012
Pos Description Part Number
U52 IC-CMOS 74LVC162245ADGG TSSOP48 403106000010
U53 IC-CMOS 74LVC162245ADGG TSSOP48 403106000010
U54 IC-CMOS 74LVC162245ADGG TSSOP48 403106000010
U56 IC-CMOS 74LVC08AD SO14 403106000009
U57 IC-CMOS 74LVC1G02GV NOR SOT753 403106000011
NOTE: The two tables above are meant to pinpoint the parts that
are unique to the respective version. Consequently they
are excerpts from the complete lists.
Parts Common to Version A
and Version B
NOTE 1: Only parts with changed quantities are shown.
NOTE 2: + means that the part has been added.
- means that the part has been deleted.
Changes refer to Version A.
+ Pos
- Pos Part Number
C36,C354,C499 C251 202202900654
C384,C390,C423,C425,C500,
C539,C561,C562,C563,C564,
C575
C250 202202900655
C253 C252,C256,C259,C431 222215364221
C254 222286115221
C565 222286115229
C33,C27 C248,C249 222286115279
C302,C343,C373,C379,C391,
C392,C413,C418,C419,C420,
C502,C537,C538,C543,C544,
C549,C560,C566,C573,C576,
C577,C578,C579,C580,C582
222286148102
C34,C35,C37,C38,C248,
C249,C301,C320,C581
C535 222286148103
C253 222286115681
C277,C505,C517,C540,C541,
C542,C545,C546,C547,C548,
C567
C255,C278,C281,C282,
C283,C284,C285,C286,
C287,C288,C301,C302,
C304,C305,C306,C307,
C308,C309,C320
222291016749
L15 242253600772
L66,L67 L18 242254900035
L18 242254943133
R585,R586,R587,R590,R591 403100115010
R368,R369 403100122040
R549,R662 403100147010
R637,R639,R644,R647,R648,
R649,R650,R651,R653,R654,
R655,R661,R667
403100210010
R523 403100210020
R20,R21,R22,R23,R425,
R541,R629,R630,R631,R632,
R663,R664,R665,R666,R668
403100210030
R638 403100210090
R590,R591 403100215010
R633,R634 R356,R357,R365,R629,R630 403100222020
R669 403100222090
R370 403100233030
8-26 Replacement Parts, Parts Unique to Version A
