Fluke T6-1000 User Manual

Electrical Tester
Required Equipment
5
Required Equipment
Table 2 is a list of equipment requirements for the performance tests of the Product.
Table 2. Required Equipment
Performance Tests
Fluke recommends a 1-year cycle for the Performance Tests. If the Product fails any test, return the Product to a Fluke Service
Center or Authorized Service Partner. See How to Contact Fluke for more information.
Before you start the Performance Tests, make sure that all test equipment has adequate warm-up time and is allowed to stabilize in
an environment of 23 °C ±5 °C.
Annunciator and Hazardous Voltage Indicator
Perform these tests as follows:
1. Set the calibrator NORMAL output to the test voltage listed in Table 3, Step 1.
2. Set the Product to the voltage (Auto Select) measurement mode.
3. Apply the voltage to the Product and verify the display reads as shown in Table 3.
Table 3. Annunciator Tests
4. Set the calibrator to the voltage and frequency listed in Table 4, Step 1.
5. Apply the voltage to the Product and verify the readings are within the display limits shown in Table 4.
Table 4. Hazardous Voltage Indicator and HOLD Function Tests
Equipment Model
Multi-Product Calibrator 5522A, 5502A/5502E, or equivalent
Precision Multimeter 8846A
DC Power Supply 0 V to 5 V adjustable
Proving Unit PRV240FS
Test Coil 9100-200 10/50-Turn Coil (Fluke PN 1583963)
Step Calibrator Output Tester Display/Indicator
15 V dc
DC annunciator ON
2 -5 V dc
DC annunciator ON
3 5 V ac, 60 Hz AC annunciator ON
Step Calibrator Output Tester Display/Indicator
1 12 V, 60 Hz
Reading: 12 V ac ±2 V
Hazardous voltage:
X LED is OFF / Y on LCD is OFF
2 38 V dc
Reading: 38 V dc ±2 V
Hazardous voltage:
X LED is ON / Y on LCD is ON
3
12 V, 60 Hz
Press HOLD on the Tester
Reading: 12 V ac ±2 V
Hazardous voltage: X LED is OFF / Y on LCD is OFF
HOLD indicator ON
4 38 V dc
Reading: 38 V dc ±2 V
Hazardous voltage:
X LED is ON / Y on LCD is ON
HOLD indicator ON

Fluke T6-1000 Specifications

General

Control type	Buttons, Rotary
Display type	-
Housing color	Black, Grey, Yellow
Jaw width (max)	17.8 mm
AC current range	- A
AC voltage range	- V
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	AA
Number of batteries supported	2
Carrying case	Yes

Weight and Dimensions

Depth	43.8 mm
Width	61.1 mm
Height	259.3 mm
Weight	350 g
