3. Push a to select Position.
: shows on the display.
4. To move the box, drag the center of the box or push
W / X / Y / Z.
5. Push s to set the change and exit the menu.
Device Settings Menu
Table 10 lists the options in the Device Settings menu.
Table 10. Device Settings Menu
Option Menu Option Description
Backlight NA
Use the slider bar to set the brightness level of the
display.
File Format
IS2
Saves images as an .is2 file.
Choose the .is2 file format when image modification and
maximum resolution is needed.
The .is2 file format consolidates the infrared image,
radiometric temperature data, visible image, notes, and
tags into a single file. To customize or separate the
visible and infrared images, use Fluke Connect desktop
software.
Use to assign an asset ID tag or to flag an asset image.
JPEG
Saves images as a .jpg file.
Choose the .jpg file format for images with the smallest
file size, where modification is not needed, and image
quality and resolution are not as important.
Units <options>
Sets the temperature units. This option is not available in
all countries.
Distance
<options>
Sets the distance to use to adjust the parallax correction
between the IR camera lens and visual light camera
lens.
Units
Sets the units to use to measure distance. This option is
not available in all countries.
Change
Filename
Filename
Prefix
Changes the default filename that starts with IR_ to a
different 4-character prefix.
Reset
Filename
Numbers
Resets the file number to 00001.
