TiS20+
Users Manual
34
AC Power Socket on Imager
Note
Make sure that the Imager is near room temperature before you connect it to the
charger. See the charging temperature specification. Do not charge in hot or cold
areas. When you charge in extreme temperatures, battery capacity may be decreased.
When you charge in extreme temperatures, the battery may not charge.
To charge the battery with the ac power socket on the Imager:
1. Connect the ac power adapter into an ac wall outlet and connect the other end to the ac
power socket on the Imager. bz flashes on the display while the battery charges.
2. Charge until the charge indicator on the display does not flash.
If you remove the Imager from the charger before a full charge shows, it can have a
reduced run-time.
3. Disconnect the ac power adapter when the smart battery is fully charged.
Optional 12 V Vehicle Charger
W Caution
To prevent damage to the Imager, remove it from the dc car charger before you
start or jump start the vehicle.
To use the 12 V vehicle charger to charge the battery:
1. Connect the 12 V adapter into the 12 V accessory socket of the vehicle.
2. Connect the other end to the ac power socket of the Imager.
bz flashes on the display while the battery charges.
3. Charge until the charge indicator on the display does not flash.
4. Disconnect the 12 V adapter and Imager when battery is fully charged.
Radio Frequency Data
See Table 10 for instructions on how to access digital copies of the Certificate IDs on the
Product.
To view the Radio Frequency Data Class B Instruction Sheet, visit http://us.fluke.com/usen/
support/manuals.
Specifications
Complete specifications are at www.fluke.com. See the TiS20+ Product Specifications.
