STATUS LED
This LED is integrated in the button and displays important information related to the status of the
battery via the following color codes.
The battery is in good condition and fully charged
The battery is in a warning state, namely a possibly
dangerous state for the battery, but still recoverable
The battery has suffered permanent damage
The battery is in selection menu mode
The battery is discharging to 30% for transport
The battery is discharging to 50% capacity for
storage
The Battery is checking its state of health
CAPACITY LEDS
These LEDs display the remaining capacity of the battery and serve as a selection menu in menu mode.
2.2.2. Displaying state of charge
A short press on the button will reveal the battery’s state of charge. If all four capacity LEDs are lit, then the
battery is fully charged. The battery will go back into standby mode after 10 seconds.
2.2.3. Entering the selection menu
A long (two second) press on the button will take you into the selection menu, which will be indicated by the
white status LED and a short beep. You can cycle through the following four menu items with a short press of
the button. You can enter the option you choose from the selection menu with a long press. You can cancel
the storage and transport mode command with a long press. At any point, the battery will go back into
standby mode after 10 seconds of inaction.
